Texas Instruments OMAP4460
Cortex™-A9 MPCore™
2 cores
1.5 GHz
512 - 1024 MB LP-DDR2
Micro-SD Socket
PowerVR SGX540 Accelerated 2D and 3D
1080p30 H.264 Encode / Decode
2x CSI, 1x CPI
1.3a 1920 x 1080
1400 x 1050 24-bit
1400 x 1050 24-bit
Resistive, Capacitive (capacitive touch is natively supported through I2C in the base configuration)
Yes
Digital
S/PDIF
Yes
x2
USB 2.0 : 2x Host, 1x OTG
x3, up to 3.6 Mbps
x2
x2
1 Wire/HDQ
on-SoM
GPMC
10/100/1000 Mbps
802.11 b/g/n
4.0
Yes
Yes
67.8 x 38.5 mm
3.3 V
1.8 V
0 to 70°C
-20 to 85°C
-40 to 85°C (excluding Wi-Fi)
1200 MHz : 1200C, 1500 MHz : 1500C
512 MB : 512R, 1024 MB : 1024R
8 GB MicroSD
10/100/1000 Mbps Ethernet + 2nd USB Host
4-wire Touch Panel.
Note: Capacitive touch is natively supported through I2C in the base configuration
Wi-Fi 802.11 b/g/n + Bluetooth 4.0
Local Bus / JTAG expansion connector
C : 0 to 70°C, E : -20 to 85°C, I : -40 to 85°C (excluding Wi-Fi)
