Texas Instruments AM62x
Cortex-A53
4 Cores
Up to 1.4GHz
400MHz Cortex-M4F and 333MHz PRU (Programmable Realtime Unit)
Up to 12,880
512MB – 4GB DDR4
8 – 128 GB
Imagination AXE-1-16M
MIPI-CSI2
Dual 1920×1080 24-bit
Resistive, Capacitive
Yes
Digital, Analog (stereo)
3 x I2S(McASP)
Yes
x1
USB 2.0: 2x OTG
x9, up to 3.6 Mbps
x5
x5
x3
On carrier
x1
x1 / x2
GPMC for external 8/16-bit parallel bus
2x 10/100/1000 Mbps
Certified single-band 802.11 b/g/n or dual-band 802.11 ac/a/b/g/n
BT/BLE 5.2
Yocto, Debian, Boot2Qt
Yes
Yes
67.8 x 33mm
3.3V
3.3V
0 to 85°C
-40 to 85°C
-40 to 85°C
5% to 95%
Processor type:
TI 6252 dual core: 2
TI 6254 quad core: 4
CPU clock speed: 1400MHz: 1400C
DDR4: 512MB: 512R, 1024 MB: 1024R, 2048 MB: 2048R, 4096 MB: 4096R
eMMC: 8 GB : 8G, 16 GB : 16G, 32 GB : 32G, 64 GB : 64G, 128 GB : 128G
Audio Codec
GbE PHY (second port always via RGMII)
Resistive touch panel controller
WB: Built-in certified single band Wi-Fi 802.11 b/g/n + Bluetooth 5.1/BLE
WBD: Built-in certified dual band Wi-Fi 802.11 ac/a/b/g/n + Bluetooth 5.2/BLE
Default: No extra interface
OSPI: Extra Octa/Quad/Dual SPI
GPMC: Extra parallel bus
MMC2: Extra SDIO/MMC2 (available only without WB/W)
Default: 3.3V over the RGMII pins
RG2CM: 1.8V over the RGMII pins
E: 0 to 85°C, I : -40 to 85°C (note: PRU available only in IT grade)
